We are a manufacturer integrating industry and trade. Welcome to visit our company. We offer a 24-month long-term warranty.
The OA-900L is a compact POS system that packs real performance into a small footprint. With a built-in 58mm or 80mm thermal printer and an integrated barcode scanner, it streamlines checkout for retail and restaurant counters. Stable and reliable for daily operation, it's a space-saving, all-in-one choice from our factory.
Get a personalized quote with volume pricing, lead times, and OEM/ODM options.
| Screen size | 15.6 inch |
| CPU | Intel i5, up to 4.1 GHz |
| Display Output | Supports asynchronous dual display (VGA/LVDS/HDMI) |
| Graphics card | Integrated Intel HD graphics card, supports DX9C |
| Input/output controller | ITE IT8786E |
| Memory | 8G /16G RAM , Support DDR4 2666MHz Single memory stick supports up to 16GB |
| Storage | 128G SSD /512 SSD 2*SATA 1*NGFF-B(for SSD) |
| Resolution | Resolution min. FHD, 16:9 |
| Screen angle adjust | Possibility to adjust the height and tilt of the screen |
| Extrenal connect port | connect a mouse and keyboard |
| Install | Possibility of mounting on a Vesa support |
| Optional parts | Built-in at least two 3-5W speakers Built-in microphone Built-in camera Bluetooth 5.1 WiFi |
| Expansion slot | 1x MPCIE slot 1x MSATA slot |
| Audio | Realtek ALC897, supports Line-Out&Line-In |
| Ethernet Lan | 2x ETH 10/100/1000 Gb/s |
| USB | 4*USB2.0 6*USB3.0 |
| COM | 4*COM pins (2*COM standard) |
| Internal I/O | 3 x USB pins 6 x COM pins 1 x 25 pin PRINT pin 1 x EDP pin/LVDS pin 1 x 4Pin SPEAKER pin 1 x 9Pin built-in audio interface (F_AUDIO) 1 x VGA display interface 1 x HDMI display interface 4 x USB3.0 interface 1 x Line Out audio interface 1 x LAN interface 1 x DCIN power interface |
| BIOS | AMI BIOS |
| Power supply | 12V DC power supply (with a dedicated 230VAC/12VDC power supply) |
| Cooling system | Passive cooling system |
| Temperature | Operating temperature: -20ºC~75ºC Environmental humidity: -15%~60% |
| Operating system | Windows 10/Windows 11 pro 64 bit |
| POS working Area | POS Monitor can be used with dispatch application - medical, energetic, transport, fire department,other |
